Bourdon Tube Test Gauges

Test gauges with bourdon tube are suitable for the measurement of positive and negative overpressure between 0-0.6 bar and 0-1,600 bar for gaseous or low-viscosity media that do not corrode brass/bronze or stainless steel.
They are applied when the measuring task requires higher accuracies than those of the bourdon tube pressure gauges, as for example for test equipment or in a laboratory.


Standard pressure gauges

RFCh / RFChG
bayonet ring case stainless steel
without or with case filling
accuracy class 0.6
nominal size: 100 (4"), 160 (6"), 250 (10")
Details DS 2201
RFSCh / RFSChG
bayonet ring case stainless steel
without or with case filling
safety category S3 according to EN 837-1
accuracy class 0.6
nominal size: 160 (6")
Details DS 2600

Special pressure gauges

RFCh
bayonet ring case stainless steel
without case filling
accuracy class 0.25
nominal size:

160 (6''), 250 (10")


Details DS 2201
RFPCh
bayonet ring case stainless steel
without case filling
test gauge with portable case
accuracy class 0.6
nominal size: 160 (6")
Details DS 2102
